20th anniversary      RadioCAD Limited      20th anniversary

The history of RadioCAD

2001

Tim is made redundant from KTL Kingston Communication in Hull and launches RadioCAD in April 2001. The phone still rings at KTL for Tim's EMC design and troubleshooting and Tim pays KTL a 10% commission on all the work they pass to him. RadioCAD's first two years are filled with KTL referrals enough to establish RadioCAD as a stable enterprise.

2002

RadioCAD and Petards jointly set up an EMC test facility at Cowden in East Yorkshire. The 3 metre semi-anechoic chamber belonged to Petards and all the other equipment to RadioCAD.

Cowden 3M semi-anechoic chamber

Cowden 3M semi-anechoic chamber

Tim also designs RadioCAD's first half-watt UHF GFSK transmitter the RA013. This becomes the module used in Ramtech 5095 and Oracle caravan alarm system. Many thousands are built under royalty to RadioCAD.

RA013 UHF TX module

RA013 UHF TX module

2003

Tim lands a new product development contract with REACT in Rotherham that becomes the start of RadioCAD's long relationship with MRT in Beverley.

First prototype SARfinder DF

First prototype SARfinder DF

This handheld 121.5 MHz direction finder was originally designed for use with the RNLI. Only two were ever made and not a single one was sold. However this became the base technology for MRT's extremely successful SARfinder DF.

2004

RadioCAD design tiny microfilters, singles and quads, for Martek that become the splitter used in Fujitsu Telecom's offering to BT as they unbundle their copper network.

Martek FTEL single microfilter

Martek FTEL single microfilter

2005-2006

Tim works on many products as an expert EMC trouble-shooter. Companies including: Effekta (UK), Road Pilot, Commtel, Zetex, Virtual Access, Allied Foods, Video Networks, Xymark, Sarian Systems, and BF Technology.

2007-2008

Tim starts the design MRT's AU9 Man-Overboard Beacon (MOB).

AU9 121.5 MHz MOB

AU9 121.5 MHz MOB

Approvals work on the product is as time consuming than the design process, particularly EUROCAE ED14. In the video Tim built his own spark chamber for explosive atmosphere testing.

AU9 Explosive atmosphere testing video

AU9 Explosive atmosphere testing video

2009-2010

RadioCAD suffers a good deal of bad debt due to the financial colapse of 2008/9, but RadioCAD survives. Tim starts work for new clients RSD Communications in Stirling, going on to design a couple of new products for them.

Printed Low-Pass Filter used in RSD's M5 Modulator

Printed Low-Pass Filter used in RSD's M5 Modulator

2011-2012

Tim develops MRT's flagship AU10 AIS Man-Overboard Beacon as well as attracting a number of new clients for RadioCAD's Cowden EMC and RF test facility. By this time Cowden has become a well established and well equipped test facility.

MRT's AU10 Man-Overboard Beacon

MRT's AU10 Man-Overboard Beacon

Tim now sits on ETSI TG26 technical committee, which means he has to travel three times a year to the South of France for 4-day long meetings followed by fine dining in Antibes and around.

ETSI

2013-2014

RadioCAD expands taking on Jef Lofts as an embedded software engineer and Tim's son Richard as an apprentice.

Richard, Danny, Tim & Jef

Here we see (left to right) Richard Jarvis, Dan Jarvis (elder son), Tim Jarvis and Jef Lofts

2015

RadioCAD becomes HID Globals preferred partner for contactless-card reader antenna design. Tim has been designing PCB reader antennas for customers like Counter Solutions in Derby. Now HID bring a steady stream of new clients to RadioCAD for new antenna designs.

HID Global

2016

Tim makes the life changing decision to change career. Tim had been working in the electronics and RF industry for 33 years having decided on being an engineer aged 9. Following the call of the Lord God Tim starts retraining for church ministry. 2016 is the year Tim scales RadioCAD finding Jef a job with client Ramtech and Richard leaves to work as an electrician.

Gateway Withernsea - Tim's first church plant

http://gateway.uk.net

2017-present

RadioCAD becomes a part-time Tim-only project as Tim continues his new life as a church minister. I still love the work I do for RadioCAD - it's always excited me and still does. Tim spends an average of 1 to 2 day a week on RadioCAD projects.
